| Model Number : | KRH-M30G-R4 |
| Brand Name : | KRONZ |
| Price : | Negotiable |
| Certification : | CE |
| Payment Terms : | T/T, Western Union, MoneyGram |
| Supply Ability : | 10000 pieces per month |
| Delivery Time : | 5-8 working days |
RFID Reader Head 13.56MHz Read Write Head with RS-485 LED Display and M30
| Model No. | KRH-M30G-R4 |
| Radio frequencies | |
| Operating frequency | 13.56MHz |
| Antenna | Integrated |
| Read /Write range | 0~70mm(Related to the tags) |
| ISO standard | ISO 15693 |
| Electrical Data | |
| Supply voltage | 9~30VDC |
| Current consumption | ＜60mA@24V |
| Communication interface | RS-485 |
| Transmission speed | 9600~115200 bps |
| Transmission distance | Shielded twisted pair,＜50m |
| Connector | 4Pin-M12-ACODED-Male |
| Permitted ambient conditions | |
| Operation temperature | -30℃~+70℃ |
| Storage temperature | -40℃~+85℃ |
| Degree of protection | IP67,according to EN 60529 |
| Shock resistance | 7M2,500 m/s2,according to EN 60721-3-7 |
| Vibration resistance | 7M2,200 m/s2,according to EN 60721-3-7 |
| Torsion and bending load | Not permitted |
| Mechanical specifications | |
| Housing Material | Brass nickel plated (metal) + Nylon (plastic) |
| Housing color | Matte silver (metal) + Black (plastic) |
| Weight | About 70g |
| Dimensions | M30 x 1.5/L=65mm |
| Housing shape | Tubular |
| Thread code | M18 x 1.5 |
| LED display | 1 x LED, blue |
| Standards, specifications, approvals | |
| Proof of suitability | CE FCC RoHS WEEE |
|
|
