RFID Reader Head 0-70mm Read Write Range with RS-232 LED Display IP67 M30X1.5

Product Description

1. Advantages:
1>. High protection level and strong corrosion resistance, can be used in harsh industrial environments
2>. High reading and writing speed, speeding up factory production rhythm and improving production efficiency
3>. Supports RS232, RS485, Modbus RTU communication, and can be quickly integrated into industrial networks such as TCP, Modbus TCP, PROFINET, EtherCat and Ethernet/IP with our Gateway Module.
4>. High stability and reliability, 7*24h operation

	Characteristics
	Design	1. LED status display
		2. Power supply and communication interface
	Area of application	Identification tasks on small assembly lines in harsh industrial environments. Mainly used in 3C, new energy and other industries

2. Electrical Interface

KRH-M30G with RS-232 interface, using a 4Pin-M12-ACODED-Male connector, the pin assignment is shown below.

	Pin	Assignment	Description
	1	+24V	Power supply positive
	2	TX	RS-232 TX
	3	0V	Power supply negative
	4	RX	RS-232 TX

3. LED operating display

The operational statuses of the reader are displayed by the LEDs. The LED can adopt the colors blue and the statuses off, on, flashing.

4. Reliable identification area

The tag should be in the center area of the sensing range as shown below.

5. Metal-free area

The KRH-M30G can be flush-mounted in metal. Allow for a possible reduction in the field data. To avoid any influence on the field data, the distance "R" should be kept to ≥40mm.

In order to avoid potential conducted interference, it is recommended to use nonmetallic brackets to cut off the transmission path of conducted interference.

6. Minimum distance between KRH-M30G readers

KRH-M30G side by side,to avoid any influence between the readers, the distance "D" should be kept to ≥80mm.

KRH-M30G face-of-face, to avoid any influence between the readers, the distance "D" should be kept to ≥150mm.

7. Technical Specifications
