    Industrial Distribution Box Single Channel 4-port NPN junction box for M12

    Ask Lasest Price
    Brand Name : KRONZ
    Model Number : MB1204-1N-CV3M/HF
    Certification : CE
    Price : Negotiable
    Payment Terms : T/T,Western Union,MoneyGram
    Supply Ability : 100000 pieces per month
    Delivery Time : 5-8 working days
    • Product Details
    • Company Profile

    Industrial Distribution Box Single Channel 4-port NPN junction box for M12

    Industrial Distribution Box Single Channel 4-port NPN junction box for M12

    Product Description

    M12 4-port Distributor Box and PVC Flexible Cable, Single Channel with LED Display, is a common connectivity component in industrial automation, primarily used for signal distribution, power management, and device interconnection. Industrial junction boxes are widely used to connect various sensors, actuators, PLCs (Programmable Logic Controllers), and other automation equipment.

    Since production lines involve extensive signal transmission (such as photoelectric sensors, proximity switches, and pressure sensors), the junction box can aggregate multiple sensor or actuator signals and transmit them to the control system via a single main cable. This reduces the number of cables, optimizes wiring structures, and improves maintenance efficiency. In addition, the modular design of the junction box allows for quick equipment replacement, minimizing downtime and enhancing production efficiency.

    Application Examples:
    • Robot welding stations on automotive manufacturing lines
    • Vision inspection systems in electronic assembly lines
    • Temperature and pressure monitoring in food processing lines


    Order Model
    MB1204-1N-CV3M/HF
    Type
    NPN
    Sheath
    PVC flexible wire
    M12 Socket
    Rated Power Ue
    24V DC/AC
    Rated Working Voltage Ub
    18...30 V DC
    Current load capacity(A)
    4 A
    Total current(A)
    6 A
    Power on indicator light
    Green LED indicator light
    Shell protection garde
    IP67(when connected correctly)
    Sheath color
    GY
    PVC flexible wire
    3*0.5+4*0.34mm2

    Dual Channel
    Pin DefinitionPin 1: (+)
    Pin 2: (S2)
    Pin 3: (-)
    Pin 4: (S1)
    Pin 5: (PE)
    LED DisplayPower (green)
    Signal S1(yellow)
    Signal S2(white)
