    3 Pin Male M12 Circular Connectors Panel Mount PCB Front Mounting Straight Contact

    Ask Lasest Price
    Brand Name : KRONZ
    Model Number : F1203M-PF/M16
    Certification : CE
    Price : Negotiable
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 100000 pieces per month
    Delivery Time : 5-8 working days
    • Product Details
    • Company Profile

    3 Pin Male M12 Circular Connectors Panel Mount PCB Front Mounting Straight Contact

    M12 Circular Connectors Panel Mount PCB Front Mounting 3 Pin Male Straight Contact


    Product Description


    M12 flange connectors follow standard IEC 61076-2-101, it have 3/4/5/8/12 pin A-coding Male and Female circular panel mount socket featuring a metal body and IP67 protection rating. The socket features an M12 thread and 4A current rating, PCB contacts termination, front mounting type.


    Technical Data


    StandardIEC 61076-2-101
    Contact nut materialBrass, nickle-plated
    Contact surface materialBrass, gold-plated
    Contact carrier materialPA, black
    Housing materialTPU, black
    Seal materialFPM/FKM
    Insulation resistance≥100MΩ
    Contact resistance≤5mΩ
    Pollution degree3
    Ambient temperature-25~+85℃
    Mating cycles>100
    Degree of protectionIP67

    Pin assignmentMounting typeCodingRated currentVoltageCable outletContacts terminationPart No.
    Front mountingA4A250VStraightPCB versionM1203M-PF/M16
