    Flange M12 Connector Female 5 Pin Panel Mounted Straight IEC 61076-2-101

    Ask Lasest Price
    Brand Name : KRONZ
    Model Number : F1205F-SR/M16
    Certification : CE
    Price : Negotiable
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 100000 pieces per month
    Delivery Time : 5-8 working days
    • Product Details
    • Company Profile

    Flange M12 Connector Female 5 Pin Panel Mounted Straight IEC 61076-2-101

    M12 Panel Mount Connector Female 5 Pin Straight Flange Connectors IEC 61076-2-101


    Product Description


    M12 panel mount connectors female 5 pin with screw locking frount mounting, its protection class IP67 dustproof and complete protection against contact.Protection against permanent submersion, Unless otherwise specified, protection up to 1 meter water depth. It can be used in areas with a pollution degree of 3. In places where contamination can occur that is conductive or can become conductive through condensation. With temperatures ranges of -25 °C/85 °C is this M12-A coded male panel mount connector designed for both severe cold and severe heat. Due to the qualified rated voltage of 60 V and the rated current of 4 A it is perfectly tuned for its field of application. It complies with the type standard IEC 61076-2-101.

    More requirement, please contact with seller.



    Technical Data


    StandardIEC 61076-2-101
    Contact nut materialBrass, nickle-plated
    Contact surface materialBrass, gold-plated
    Contact carrier materialPA, black
    Housing materialTPU, black
    Seal materialFPM/FKM
    Insulation resistance≥100MΩ
    Contact resistance≤5mΩ
    Pollution degree3
    Ambient temperature-25~+85℃
    Mating cycles>100
    Degree of protectionIP67

    Pin assignmentMounting typeCodingRated currentVoltageCable outletContacts terminationPart No.
    Front mountingA4A60VStraightSolder cupF1205M-SF/M16
